# | Ref. | unds. | Precio/unidad | |
---|---|---|---|---|
1 |
BX9F74810000 BOARD, FOOTREST |
1 | 54,04 € | + |
2 |
904800186800 GROMMET |
1 | 2,69 € | + |
3 |
901830580700 NUT, SPRING |
1 | 0,49 € | + |
4 |
905201082500 DAMPER, PLATE |
1 | 0,37 € | + |
5 |
BX9F74130000 COVER, FOOTREST |
1 | 23,62 € | + |
6 |
901830681500 NUT, SPRING |
1 | 0,42 € | + |
7 |
BX9F171L00P0 MOLE, SIDE COVER 1 |
1 | 81,72 € | + |
7 |
BX9F171L00P3 MOLE, SIDE COVER 1 |
1 | 81,72 € | + |
7 |
BX9F171L00P2 MOLE, SIDE COVER 1 |
1 | 81,72 € | + |
8 |
901670580100 SCREW, TAPPING |
1 | 1,28 € | + |
9 |
90109068B500 BOLT |
1 | 1,19 € | + |
10 |
901190605100 BOLT, WITH WASHER |
1 | 1,01 € | + |
11 |
902690900500 RIVET |
1 | 0,42 € | + |
12 |
BF6F172W0100 COVER |
1 | 1,50 € | + |
13 |
BX9F74880000 BOARD, FOOTREST 2 |
1 | 54,04 € | + |
14 |
904800186800 GROMMET |
1 | 2,69 € | + |
15 |
901830580700 NUT, SPRING |
1 | 0,49 € | + |
16 |
905201082500 DAMPER, PLATE |
1 | 0,37 € | + |
17 |
BX9F74230000 COVER, FOOTREST |
1 | 23,62 € | + |
18 |
901830681500 NUT, SPRING |
1 | 0,42 € | + |
19 |
BX9F171M00P2 MOLE, SIDE COVER 2 |
1 | 81,72 € | + |
19 |
BX9F171M00P3 MOLE, SIDE COVER 2 |
1 | 81,72 € | + |
19 |
BX9F171M00P0 MOLE, SIDE COVER 2 |
1 | 81,72 € | + |
20 |
901670580100 SCREW, TAPPING |
1 | 1,28 € | + |
21 |
90109068B500 BOLT |
1 | 1,19 € | + |
22 |
901190605100 BOLT, WITH WASHER |
1 | 1,01 € | + |
23 |
902690900500 RIVET |
1 | 0,42 € | + |
24 |
BX9F17110000 COVER, SIDE 1 |
1 | 118,67 € | + |
25 |
BX9F84971000 PLATE 3 |
1 | 28,97 € | + |
26 |
901670580100 SCREW, TAPPING |
1 | 1,28 € | + |
27 |
977025001200 SCREW, TAPPING |
1 | 0,49 € | + |
28 |
901830580700 NUT, SPRING |
1 | 0,49 € | + |
29 |
BX9F17210000 COVER, SIDE 2 |
1 | 118,67 € | + |
30 |
BX9F846H1000 PLATE,4 |
1 | 28,97 € | + |
31 |
901670580100 SCREW, TAPPING |
1 | 1,28 € | + |
32 |
977025001200 SCREW, TAPPING |
1 | 0,49 € | + |
33 |
901830580700 NUT, SPRING |
1 | 0,49 € | + |
34 |
BX9F74830000 MAT 1 |
1 | 16,41 € | + |
35 |
BX9F74840000 MAT 2 |
1 | 16,41 € | + |
36 |
BX9F74930000 MAT 3 |
1 | 22,30 € | + |
37 |
BX9F74940000 MAT 4 |
1 | 30,15 € | + |
