# | Ref. | unds. | Precio/unidad | |
---|---|---|---|---|
1 |
B2UF83110000 LEG SHIELD 1 |
1 | 54,83 € | + |
2 |
977025001600 SCREW, TAPPING |
5 | 0,51 € | + |
3 |
901830580700 NUT, SPRING |
5 | 0,51 € | + |
4 |
904800155900 GROMMET |
1 | 1,30 € | + |
5 |
904801339800 GROMMET |
1 | 1,91 € | + |
6 |
904801382300 GROMMET |
1 | 6,53 € | + |
7 |
90387068U700 COLLAR |
1 | 4,14 € | + |
8 |
958220602000 BOLT, FLANGE |
1 | 1,02 € | + |
9 |
B2UF835U00P3 PANEL 1 |
1 | 61,28 € | + |
9 |
B2UF835U00P1 PANEL 1 |
1 | 61,28 € | + |
10 |
901110582100 BOLT, HEXAGON SOCKET BUTTON |
1 | 0,75 € | + |
11 |
B2UXF83G00P3 PANEL COMP 2 |
1 | 58,79 € | + |
11 |
B2UXF83G30P1 PANEL COMP 2 |
1 | 58,79 € | + |
12 |
BUVF15680000 .LABEL, WARNING |
1 | 4,36 € | + |
13 |
901110582100 BOLT, HEXAGON SOCKET BUTTON |
1 | 0,75 € | + |
14 |
B2UF839R00P0 PANEL, ACCESSORY |
1 | 56,73 € | + |
15 |
977025001200 SCREW, TAPPING |
1 | 0,51 € | + |
16 |
B2UXF83N1000 LEG SHIELD ASSY 2 |
1 | 108,25 € | + |
17 |
904801339800 GROMMET |
1 | 1,91 € | + |
18 |
904800155900 GROMMET |
1 | 1,30 € | + |
19 |
901830580700 NUT, SPRING |
5 | 0,51 € | + |
20 |
90183050A700 NUT, SPRING |
1 | 2,87 € | + |
21 |
BUVF83150000 .EMBLEM |
1 | Obsoleta | |
22 |
977025001600 SCREW, TAPPING |
5 | 0,51 € | + |
23 |
B2UXF8AB50P2 PLATE,1 SUB ASSY. |
1 | 26,10 € | + |
23 |
B2UXF8AB40P0 PLATE,1 SUB ASSY. |
1 | 26,10 € | + |
24 |
B2UF83150000 .EMBLEM |
1 | 0,56 € | + |
25 |
901830506700 NUT, SPRING |
1 | 1,21 € | + |
26 |
B2UXF8AC40P0 PLATE,2 SUB ASSY. |
1 | 26,10 € | + |
26 |
B2UXF8AC50P2 PLATE,2 SUB ASSY. |
1 | 26,10 € | + |
27 |
B2UF83150000 .EMBLEM |
1 | 0,56 € | + |
28 |
901830506700 NUT, SPRING |
1 | 1,21 € | + |
29 |
B2UF83850100 COVER, LOWER |
1 | 51,73 € | + |
30 |
90183050A700 NUT, SPRING |
1 | 2,87 € | + |
31 |
970170601400 BOLT |
5 | 0,23 € | + |
32 |
90387068S100 COLLAR |
1 | 1,80 € | + |
33 |
901830580700 NUT, SPRING |
5 | 0,51 € | + |
34 |
B2UF15520000 FENDER, INNER |
1 | 73,89 € | + |
35 |
977025001200 SCREW, TAPPING |
1 | 0,51 € | + |
36 |
903381480200 PLUG |
1 | 0,60 € | + |
37 |
B7JF83790000 HOOK |
1 | 8,26 € | + |
38 |
90109068C800 BOLT |
1 | 2,55 € | + |
