# | Ref. | unds. | Precio/unidad | |
---|---|---|---|---|
1 |
BK6E74110000 AXLE, MAIN |
1 | 163,79 € | + |
2 |
BK6E71510000 GEAR, 5TH PINION (23T) |
1 | 57,49 € | + |
3 |
902091728500 WASHER |
1 | 3,93 € | + |
4 |
934102003800 CIRCLIP |
1 | 1,06 € | + |
5 |
5D7E71310000 GEAR, 3RD PINION (22T/21T) |
1 | 126,10 € | + |
6 |
BK6E71610000 GEAR, 6TH PINION (25T) |
1 | 56,15 € | + |
7 |
3C1E71210000 GEAR, 2ND PINION (16T) |
1 | 49,34 € | + |
8 |
93306054XF00 BEARING |
1 | 28,08 € | + |
9 |
93306252YN00 BEARING |
1 | 30,25 € | + |
10 |
3C1E74710000 PLATE, COVER |
1 | 7,62 € | + |
11 |
9011006X8600 BOLT, HEXAGON SOCKET HEAD |
1 | 4,35 € | + |
12 |
BK6E74210000 AXLE, DRIVE |
1 | 78,46 € | + |
13 |
3C1E72110000 GEAR, 1ST WHEEL (34T) |
1 | 81,59 € | + |
14 |
903871780400 COLLAR |
1 | 9,97 € | + |
15 |
BK6E72510000 GEAR, 5TH WHEEL (22T) |
1 | 31,70 € | + |
16 |
902091820800 WASHER |
1 | 1,13 € | + |
17 |
934102203900 CIRCLIP |
1 | 3,43 € | + |
18 |
BK6E72410000 GEAR, 4TH WHEEL (24T) |
1 | 58,30 € | + |
19 |
BK6E72310000 GEAR, 3RD WHEEL (30T) |
1 | 81,59 € | + |
20 |
5D7E72610000 GEAR, 6TH WHEEL (21T) |
1 | 54,77 € | + |
21 |
BK6E72210000 GEAR, 2ND WHEEL (30T) |
1 | 63,28 € | + |
22 |
902012279300 WASHER, PLATE |
1 | 1,92 € | + |
23 |
934102203900 CIRCLIP |
1 | 3,43 € | + |
24 |
90201173F400 WASHER, PLATE |
1 | 2,74 € | + |
25 |
93306253X200 BEARING |
1 | 23,36 € | + |
26 |
93306272YC00 BEARING |
1 | 17,62 € | + |
27 |
931022282700 OIL SEAL |
1 | 6,71 € | + |
28 |
938221480000 SPROCKET, DRIVE (14T) |
1 | 15,19 € | + |
29 |
1S7E74560000 HOLDER, SPROCKET |
1 | 0,33 € | + |
30 |
95E320601000 BOLT, FLANGE DEEP RECESS |
1 | 2,30 € | + |
