# | Ref. | unds. | Precio/unidad | |
---|---|---|---|---|
1 |
B5GF835U01P0 PANEL 1 |
1 | 278,79 € | + |
1 |
B5GF835U01P1 PANEL 1 |
1 | 278,79 € | + |
2 |
901830504200 NUT, SPRING |
1 | 0,49 € | + |
3 |
9016905X0300 TAPPING SCREW |
1 | 3,43 € | + |
4 |
B5GF835V01P0 PANEL 2 |
1 | 278,79 € | + |
4 |
B5GF835V01P1 PANEL 2 |
1 | 278,79 € | + |
5 |
901830504200 NUT, SPRING |
1 | 0,49 € | + |
6 |
9016905X0300 TAPPING SCREW |
1 | 3,43 € | + |
7 |
B5GF837L0000 PANEL CONSOLE 1 |
1 | 35,07 € | + |
8 |
902690600100 RIVET |
1 | 1,24 € | + |
9 |
9016905X0300 TAPPING SCREW |
1 | 3,43 € | + |
10 |
B5GF837M0000 PANEL, DE CONSOLA 2 |
1 | 35,07 € | + |
11 |
902690600100 RIVET |
1 | 1,24 € | + |
12 |
9016905X0300 TAPPING SCREW |
1 | 3,43 € | + |
13 |
B5GF838500P0 CUBIERTA INFERIOR |
1 | 101,57 € | + |
13 |
B5GF838500P1 CUBIERTA INFERIOR |
1 | 101,57 € | + |
14 |
901830504200 NUT, SPRING |
1 | 0,49 € | + |
15 |
904801280800 GROMMET |
1 | 0,17 € | + |
16 |
903870689900 COLLAR |
1 | 0,86 € | + |
17 |
901110608400 BOLT, HEXAGON SOCKET BUTTON |
1 | 1,97 € | + |
18 |
B5GF839500P0 CUBIERTA INFERIOR |
1 | 101,57 € | + |
18 |
B5GF839500P1 CUBIERTA INFERIOR |
1 | 101,57 € | + |
19 |
901830504200 NUT, SPRING |
1 | 0,49 € | + |
20 |
904801280800 GROMMET |
1 | 0,17 € | + |
21 |
903870689900 COLLAR |
1 | 0,86 € | + |
22 |
901110608400 BOLT, HEXAGON SOCKET BUTTON |
1 | 1,97 € | + |
23 |
B5GF836K0000 PANEL 1 |
1 | 26,72 € | + |
24 |
904800155900 GROMMET |
1 | 1,28 € | + |
25 |
9016705X0600 SCREW, TAPPING |
1 | 1,73 € | + |
26 |
902690600100 RIVET |
1 | 1,24 € | + |
27 |
B5GF836L0000 PANEL 2 |
1 | 26,72 € | + |
28 |
904800155900 GROMMET |
1 | 1,28 € | + |
29 |
9016705X0600 SCREW, TAPPING |
1 | 1,73 € | + |
30 |
902690600100 RIVET |
1 | 1,24 € | + |
31 |
BK6F836M0000 PANEL 3 |
1 | 16,03 € | + |
32 |
9016705X0600 SCREW, TAPPING |
1 | 1,73 € | + |
33 |
902690600100 RIVET |
1 | 1,24 € | + |
