# | Ref. | unds. | Precio/unidad | |
---|---|---|---|---|
1 |
BC3274810000 BOARD, FOOTREST |
1 | 150,78 € | + |
2 |
B3T274530100 COVER 1 |
1 | 34,17 € | + |
3 |
901190623500 BOLT, WITH WASHER |
1 | 1,06 € | + |
4 |
977025001200 SCREW, TAPPING |
1 | 0,49 € | + |
5 |
977025001600 SCREW, TAPPING |
1 | 0,49 € | + |
6 |
901830504200 NUT, SPRING |
1 | 0,49 € | + |
7 |
90183060A600 NUT, SPRING |
1 | 2,89 € | + |
8 |
904800155900 GROMMET |
1 | 1,28 € | + |
9 |
BC32837L0000 PANEL, CONSOLE 1 |
1 | 82,27 € | + |
10 |
901090501800 BOLT |
1 | 1,65 € | + |
11 |
977025001200 SCREW, TAPPING |
1 | 0,49 € | + |
12 |
901830504200 NUT, SPRING |
1 | 0,49 € | + |
13 |
BC3274880000 BOARD, FOOTREST 2 |
1 | 150,78 € | + |
14 |
B3T274630100 COVER 2 |
1 | 34,17 € | + |
15 |
905202000900 DAMPER, PLATE |
1 | 3,06 € | + |
16 |
905202001100 DAMPER, PLATE |
1 | 10,42 € | + |
17 |
901190623500 BOLT, WITH WASHER |
1 | 1,06 € | + |
18 |
977025001200 SCREW, TAPPING |
1 | 0,49 € | + |
19 |
977025001600 SCREW, TAPPING |
1 | 0,49 € | + |
20 |
901830504200 NUT, SPRING |
1 | 0,49 € | + |
21 |
90183060A600 NUT, SPRING |
1 | 2,89 € | + |
22 |
904800155900 GROMMET |
1 | 1,28 € | + |
23 |
BC32837M0000 PANEL, CONSOLE 2 |
1 | 82,27 € | + |
24 |
901090501800 BOLT |
1 | 1,65 € | + |
25 |
977025001200 SCREW, TAPPING |
1 | 0,49 € | + |
26 |
901830504200 NUT, SPRING |
1 | 0,49 € | + |
27 |
2PW274830000 MAT 1 |
1 | 16,31 € | + |
28 |
2PW274840000 MAT 2 |
1 | 16,31 € | + |
29 |
2PW274130000 COVER, FOOTREST |
1 | 23,54 € | + |
30 |
2PW274230000 COVER, FOOTREST |
1 | 23,54 € | + |
31 |
BC3274930000 MAT 3 |
1 | 25,90 € | + |
32 |
BC3274940000 MAT 4 |
1 | 25,90 € | + |
