# | Ref. | unds. | Precio/unidad | |
---|---|---|---|---|
1 |
BX9F11101100 FRAME COMP. |
1 | 1.486,55 € | + |
2 |
905200401500 DAMPER, PLATE |
1 | 0,49 € | + |
3 |
BBRF414G2000 SEAL |
1 | 2,84 € | + |
4 |
BX9H251P0100 BRACKET, MAIN SWITCH |
1 | 16,41 € | + |
5 |
901490684000 SCREW |
1 | 0,75 € | + |
6 |
B74F149S0000 BRACKET 5 |
1 | 3,43 € | + |
7 |
95E320601200 BOLT, FLANGE DEEP RECESS |
1 | 0,17 € | + |
8 |
B74F14000200 ENGINE BRACKET COMP. |
1 | 75,02 € | + |
9 |
B74F21410000 SHAFT, PIVOT |
1 | 27,24 € | + |
10 |
901051280600 BOLT, FLANGE |
1 | 4,39 € | + |
11 |
901051280500 BOLT, FLANGE |
1 | 4,39 € | + |
12 |
956021220000 NUT, SELF-LOCKING |
1 | 1,65 € | + |
13 |
BX9F13100100 STEERING HEAD PIPE COMPLETE |
1 | 110,28 € | + |
14 |
901161280200 BOLT, STUD |
1 | 7,31 € | + |
15 |
BX9F33630000 COLLAR 1 |
1 | 2,69 € | + |
16 |
BX9F33640000 COLLAR 2 |
1 | 3,38 € | + |
17 |
956021220000 NUT, SELF-LOCKING |
1 | 1,65 € | + |
18 |
5XVF51880100 CAP |
1 | 3,16 € | + |
19 |
901051281300 BOLT, FLANGE |
1 | 1,28 € | + |
20 |
901051281400 BOLT, FLANGE |
1 | 1,28 € | + |
21 |
BX9F141A0000 BRACKET 1 |
1 | 6,40 € | + |
22 |
BEDH21280000 BRACKET, BATTERY |
1 | 55,34 € | + |
23 |
5D6F16490000 DAMPER |
1 | 0,10 € | + |
24 |
95D320601200 BOLT, FLANGE DEEP RECESS |
1 | 1,28 € | + |
25 |
BX9F122A0000 STAY 1 |
1 | 6,40 € | + |
