# | Ref. | unds. | Precio/unidad | |
---|---|---|---|---|
1 |
B6HF11100100 FRAME COMP. |
1 | 815,44 € | + |
2 |
B6HH251P0000 BRACKET, MAIN SWITCH |
1 | 49,07 € | + |
3 |
901090631800 BOLT |
1 | 1,28 € | + |
4 |
5D9F414G0000 SEAL |
1 | 4,99 € | + |
5 |
B6HF14100000 ENGINE BRACKET COMP. |
1 | 60,62 € | + |
6 |
B65F117G0000 PROTECTOR |
1 | 2,56 € | + |
7 |
903881081800 DAMPER |
1 | 6,12 € | + |
8 |
903871085700 COLLAR |
1 | 3,60 € | + |
9 |
B65F113B0000 DAMPER |
1 | 0,59 € | + |
10 |
B65F21410000 SHAFT, PIVOT |
1 | 14,11 € | + |
11 |
956021020000 NUT, SELF-LOCKING |
1 | 3,43 € | + |
12 |
901051028300 BOLT, FLANGE |
1 | 3,48 € | + |
13 |
956021020000 NUT, SELF-LOCKING |
1 | 3,43 € | + |
14 |
44DF71140000 STOPPER, MAIN STAND |
1 | 5,80 € | + |
15 |
903870882100 COLLAR |
1 | 0,86 € | + |
16 |
90105088E300 BOLT, FLANGE |
1 | 0,49 € | + |
17 |
956020820000 NUT, U FLANGE |
1 | 3,06 € | + |
18 |
B6HF83560000 STAY 1 |
1 | 138,16 € | + |
19 |
95D320805000 BOLT, FLANGE DEEP RECESS |
1 | 0,55 € | + |
20 |
901790500300 NUT |
1 | 4,52 € | + |
21 |
904801422900 GROMMET |
1 | 1,01 € | + |
22 |
90387068N800 COLLAR |
1 | 0,86 € | + |
23 |
95D320602000 BOLT, FLANGE DEEP RECESS |
1 | 1,01 € | + |
24 |
90105068C500 BOLT, FLANGE |
1 | 0,59 € | + |
25 |
904801780200 GROMMET |
1 | 1,28 € | + |
26 |
B6HF588F0000 HOLDER, BRAKE HOSE 5 |
1 | 9,50 € | + |
27 |
95D320601200 BOLT, FLANGE DEEP RECESS |
1 | 1,28 € | + |
